GDA 240W AC/DC DIN Rail Enclosure Power Supply

A rugged family of Industrial DIN Rail mounted DC Power Supplies with PWM design. These are UL Class II with operating temperatures from -4 to 159°F (-20 to 71°C). The single phase models accept a wide universal input range 90-264V AC. All models feature touch-proof spring clamp terminations for input & output wire connections.

Features

DIN rail mounting
AC input voltage 115/230 VAC (selectable), 47-63Hz
Finger safe terminals - screw terminal on all 240W models
Status indicator GREEN LED for DC ON at start-up
Status indicator RED LED for DC Low indication after start-up
Relay N.O. contact for DC ON at start-up (24V model only)
Operating temperature range -40 to 160F, continuous operation (no de-rating) to 142F
Output overload, over voltage, short circuit & no load protection
Input line fuse & filter with surge voltage protection & inrush current limiter
UL 508 (E222875), CE
Input isolation voltage is 3kV, and input isolation resistance is 100 Mega ohm
Power factor correction on 240 watt
Parallel operation switch selectable on 240 watt
Metal case for all 240W models; IP20 Protection

Specifications

Phase: Single Phase
Rated Power: 240–300 W
Input Voltage: 100–240 VAC
Input Frequency: 47–63 Hz
Output Voltage Options: 12 VDC / 24 VDC / 48 VDC
Output Voltage Adjustment Range (24 V): 22.5–28.5 V
Output Voltage Adjustment Range (48 V): 47–56 V
Power Factor Correction: Yes
Parallel Operation Capability: Yes (Selectable)
Overload Protection: Yes
Overvoltage Protection: Yes
Short Circuit Protection: Yes
No Load Protection: Yes
Input Protection: Line fuse, EMI filter, inrush current limiter
Isolation Voltage: 3 kV transformer isolation
DC ON Indicator: Green LED
DC LOW Indicator: Red
LED Relay Output (DC OK): Yes
Mounting Type: DIN Rail
Terminal Type: Screw Terminal
Housing Material: Metal
UL Certification: UL 508
CE Marking: Yes
Manufacturer: Genesis Automation
Country of Origin: USA

Model Numbers

GDA240-24A - 240W DC, 24V/10A PFC & Parallel UL508
GDA240-48A - 240W DC, 48V/5A PFC & Parallel UL508
