8" Slimline Enclosure Filter Fan 47 CFM Reversible Air Flow

Designed for easy snap-in mounting and made out of high resistance, self-extinguishing ABS UL94V0 plastic. The housing color is machinery grey(RAL7035). The GHV10 models have a hinged front grill for easy access. The air flow rate is 21cfm (35 m3/Hr). They provide an NEMA-12/IP54 protection degree. These are ball bearing fans with a reversible motor having MTBF of 40,000 hours.

Features

8" Enclosure Filter Fans
Single Hole Cutout, Snap-In Installation
Air Flow 47 cfm
Reversible air flow by reversing fan
Easy maintenance and filter replacement
Protection Class: IP54 (NEMA-12)
Electrical connections with spring terminals
MBTF: 40,000 hours
Operating Temperature: 14/140°F (-10/+60°C)
Approval: CE & cUL

Specifications

Product Model: GKV20SL220
Reversible Fan Model: YES
Voltage / Phase / Frequency: 230‑1‑50/60
Height / Width / Depth (Inch): 8x8x4.25
Height / Width / Depth (mm): 204x204x108
Power/Current absorbed (Watt/Amp): 20W/0.09A
Temperature limits (°F): 14 to 140F
Temperature limits (°C): -10 to 60C
Noise level (dB(A)): 46
Air flow (cfm): 47
Air flow (m³/h): 80

Model Types
GHV20SL220 8" Slim Enclosure Filter Fan, 230 VAC, 47 cfm
GHV20SL211 8" Slim Enclosure Filter Fan, 24 DC, 88 cfm
GHF20 8" Exhaust Filter
